Description
The DJI Fly Cart 30 is a cutting-edge transport solution tailored for professional drone operators and avid enthusiasts. Designed for efficiency and organization, this versatile cart ensures your DJI drones and accessories are always ready for action.
| Key Feature | Details |
|---|---|
| Spacious Storage | Generous interior for holding multiple drones, batteries, cameras, and essential accessories, ensuring everything is at your fingertips. |
| Customizable Compartments | Adjustable dividers allow you to personalize the interior layout, providing optimal organization and protection for your gear. |
| Robust Mobility | Equipped with durable, all-terrain wheels for easy navigation across various environments. |
| Weather-Resistant Protection | Constructed with high-quality, weather-resistant materials to defend your gear from rain, dust, and other environmental threats. |
| Quick Access Points | Design includes multiple access points for rapid retrieval of items, allowing you to focus on your aerial missions without unnecessary delays. |
| Integrated Charging Station | Certain models feature built-in charging capabilities, enabling you to recharge your batteries directly from the cart. |
| Lightweight & Portable | Despite its robust build, the cart remains lightweight for easy transportation. |
| Specification | Details |
|---|---|
| Weight | 42.5 kg (without battery), 65 kg (with two DB2000 batteries) |
| Maximum Takeoff Weight | 95 kg (with cargo at sea level) |
| Max Diagonal Wheelbase | 2200 mm |
| Dimensions | 1590 x 1900 x 947 mm (LxWxH) with arms unfolded and propellers folded 2800 x 3085 x 947 mm (LxWxH) with arms and propellers unfolded 1115 x 760 x 1027 mm (LxWxH) with arms and propellers folded |
| Folding Method | Toward body |
| Battery Capacity | Supports 2 batteries |
| Hovering Endurance (empty weight with max battery capacity) | 29 mins (dual battery mode), 15 mins (single battery mode) |
| Hovering Endurance (max weight with max battery capacity) | 18 mins (30 kg load, dual battery mode), 8 mins (40 kg load, single battery mode) |
| Maximum Flight Distance (empty weight with max battery capacity) | 28 km (dual battery mode), 12 km (single battery mode) |
| Maximum Flight Distance (max weight with max battery capacity) | 16 km (30 kg load, dual battery mode), 8 km (40 kg load, single battery mode) |
| Maximum Flight Time (max weight with max battery capacity) | 18 mins (30 kg load, dual battery mode), 9 mins (40 kg load, single battery mode) |
| Operating Temperature | -20° to 45° C |
| Ingress Protection Rating | IP55 |
| Hovering Accuracy (with strong GNSS signal) | With RTK: ±10 cm horizontal, ±10 cm vertical Without RTK: ±60 cm horizontal, ±30 cm vertical (radar enabled: ±10 cm) |
| RTK/GNSS Operating Frequency | RTK: GPS L1/L2, Galileo F1/F2, BeiDou B1I/B2I/B3I, Galileo E1/E5b, QZSS L1/L2 GNSS: GPS L1, BeiDou B1I, Galileo F1, Galileo E1, QZSS L1 |
| Maximum Pitch Angle | 30° |
| Maximum Ascent Speed | 5 m/s |
| Maximum Descent Speed | 3 m/s (vertical) 5 m/s (tilted) |
| Maximum Horizontal Speed | 20 m/s |
| Maximum Flight Altitude | 6000 m (without payload) |
| Maximum Wind Speed Resistance | 12 m/s |
| Propulsion System | Stator Size: 100×33 mm Motor KV Value: 48 rpm/V Maximum Motor Power: 4000 W per rotor Propeller Material: Carbon fiber composite Propeller Diameter: 54 inches Propeller Type: Foldable double-blade propellers Main Rotor Diameter: 1375 mm Rotor Quantity: 8 |
| LED Light | Effective Illumination Distance: 10 m Illumination Mode: 60 Hz, automatically activates based on ambient light |
| DJI O3 Image Transmission | Model: Pigeon (with DDR)-2T4R Signal Effective Distance: 20 km (FCC), 8 km (CE/SRRC/MIC) O3 Operating Frequency: 2.4000 to 2.4835 GHz, 5.725 to 5.850 GHz Data Security: AES-256 ADS-B: Supported |
| Forward and Backward Active Phased Array Radar | Model Number: RD241608RF (forward), RD241608RB (backward) Altitude Detection: Fixed range of 1.5-200 m Rear Obstacle Avoidance: 1.5-50 m |
| Binocular Vision System | FOV: Horizontal: 90°, Vertical: 106° Work Environment Requirements: Normal lighting with clear textured surfaces |
| FPV Camera | Resolution: 1920×1440 DFOV: 149° Frame Rate: 30 fps Type: Full HD FPV Single Axis Gimbal Camera Fill Light: Supported |
| Cargo Case | Dimensions: 754x472x385 mm (LxWxH) Inner Space: 573x416x305 mm (LxWxH) Material: EPP with aluminum alloy frame Weight: Approximately 3 kg Load Capacity: 0-40 kg |
| Parachute | Maximum Payload: ≤ 95 kg Dimensions: 300x200x120 mm (LxWxH) Weight: Approximately 2.1 kg Automatic Reaction Time: Approximately 1000 ms Surface Area: Approximately 22 ㎡ Minimum Opening Height: 60 m |
| Winch System (Optional) | Model: A2EWI-30A Payload Capacity: 5-30 kg (dual battery), 5-40 kg (single battery) Cable Length: 20 m Max Retraction Speed: 0.8 m/s Operating Temperature: -20° to 45° C |
| DJI DB2000 Intelligent Battery | Model: DB2000 Capacity: 38000 mAh Nominal Voltage: 52.22 V Type: 14S1P Energy: 1984.4 Wh Weight: Approximately 11.3 kg |
